SOFFIO HPHigh-static ductable unit 150 Pa
Sturdy, quiet and optimized for centralized systems.
The ideal solution for open spaces, offices and commercial areas requiring high airflow rates and continuous performance. High power, smart management of up to 250 units and optimized energy consumption.
High static pressure: 150 Pa effective
The fans are designed to deliver 150 Pa at nominal airflow, as specified in the technical sheet.
Perfect for centralized systems with long or branched duct networks.
Solid and quiet structure
Panels in thick galvanized steel (1.00–1.50 mm) with cross-linked polyethylene insulation, 10 mm thick, fire-rated class B-s2d0 / BL-s1d0 according to EN13501-1.
Reduced vibrations, long service life and low noise emission.
Simplified maintenance
The filter can be removed from the bottom or sides without tools.
All electrical and electronic components are easily accessible, with no need to disconnect the ducts.
High-efficiency heat exchangers
CU/AL coils – 3/8" diameter, corrugated fins, and easily accessible air vent valves.
Nominal pressure: PN8.
High pressure and airflow
Thanks to reinforced fans and modular sections, Soffio HP is ideal for medium-to-large environments such as offices, shops, clinics and libraries.
Advanced control and BMS integration
Smart control system featuring:
- Master/Slave management up to 24 units
- Supervision of up to 250 units
- TOP3, SP3, BMS-SP3 and Modbus protocol
AC or EC motors
-
AC version: 3-speed motor
-
EC version: continuously variable (6–10 V). The EC motor ensures up to 35% energy savings
Soffio HP ensures stable comfort all year round, even in large ducted systems. Modulating airflow and high thermal/cooling capacities guarantee uniform well-being and reliable operation under all conditions.
Summer
Cooling capacity from 4.0 to 69.0 kW
Ideal for large areas, open spaces and commercial applications.
Winter
Heating capacity from 5.0 to 74.0 kW
Stable ducted airflow and high available pressure even at higher speeds.
Mid-seasons
Modulated airflow (EC motor) maintains consistent comfort while reducing energy consumption.
Gallery
Choose the configuration that best suits your needs
Configurations
SOFFIO HP is available in:
- SP – single panel (standard)
- DP – double panel (on request)
Available sizes
21 – 38 – 81 – 91 – 101 – 121
Available motors
- AC
- EC
| Cooling | kW | 4,0 – 69,0 (AC/EC) |
| Heating | kW | 5,0 – 74,0 |
| Air flow rate |
m³/h | 857 – 8800 |
| Available static pressure |
Pa | 150 |
| Sound data |
dB(A) | Sound power (supply): 67–83 dB(A) (AC) Typical sound pressure: indicative values calculated with 9 dB(A) attenuation for 100 m³ rooms |
Designed to maximize performance in large systems while minimizing consumption, vibration and maintenance.
Energy-saving EC motor
Up to 35% energy reduction thanks to continuous speed modulation.
Safe, sound-absorbing materials
Self-extinguishing thermal-acoustic insulation (class B-s2d0 / BL-s1d0) and 1–1.5 mm galvanized steel panels ensure durability and quiet operation.
High-efficiency coils
CU/AL coils with easily accessible vent valves ensure optimal long-term performance.
Download the full brochure
All detailed technical information, available models, possible configurations, and installation diagrams in a single PDF document.
• Complete electrical and hydraulic diagrams • Dimensions and weights of all models • Available accessories and compatibility • Detailed performance curves
Area reserved for designers and installers
Access the complete technical documentation reserved for professionals
How SOFFIO HP is made
Each SOFFIO HP unit is designed, assembled and tested entirely in our facilities in Italy.
We do not market third-party products: we have been manufacturers since 1986, with over 30 years of experience in dehumidifiers for radiant systems.
In-house design
Every component is designed by specialized technicians.
Made-in-Italy assembly
Assembly and testing performed in Italy with European certifications.
Individual testing
Each unit is individually tested before shipment.
Answers to the most common questions about SOFFIO HP
Soffio HP delivers 150 Pa at nominal airflow, ideal for complex ducted systems.
Yes. The coil connections can be swapped directly on site.
Yes. EC versions feature continuous fan speed modulation and up to 35% energy savings.
Yes. Soffio HP is compatible with TOP3, SP3, Modbus and allows management of up to 250 units.
21, 38, 81, 91, 101, 121.
The filter and internal components are accessible from the bottom or sides without disconnecting the ducts.
Offices, shops, clinics and medium-to-large spaces with ducted air distribution.
